Globe 2600
GLOBE fixed bench 2600 X 1000 X1350 mod. 2600 - 5 axis .
Powerful and versatile, this machine is particularly suitable for machining with large material removal.
The lead screws of the three axes are recirculating balls, rectified, with double preloaded nut, and each axis is provided with an electromagnetic locking brake.
To ensure maximum rigidity and precision during inversions, the screws are pre-tensioned.
The base, the upright, the table, the bracket and the ram are made of very thick castings and equipped with numerous internal ribs which allow to absorb vibrations in an optimal way during the most demanding machining operations.
The machine is equipped with bi-rotary heads, manual or automatic, with ISO 50 spindle taper.
BOARD
Board size: 3100x900(1050) mm
T-slot width: 22mm
T-slot pitch: 125 mm
Maximum admitted weight: 8000Kg
STROKE
Longitudinal stroke: 2600 mm
Transversal stroke: 1000(1200) mm
Vertical stroke: 1050-1350-1600-2000 mm
